CE Approved Tracking Index Tester for Lab Testing
1. Reference:
This Tracking Index Apparatus is strictly designed and manufactured in accordance
With IEC60112, IEC60335-1, IEC60598-1 and GB4207.
2. Application:
This Tracking index apparatus is a fully automatic instrument contained in its own cabinet to maximize the safety of the operator and mainly used test the resistance Tracking Performance of solid electrical insulation materials when they are exposing in electric affect impurity water situation. Mainly used for determination PTI and CTI items.
Inside the well lit cabinet, a test specimen is placed on a glass plate and two platinum electrodes are lowered on the top surface.
A gauge block is supplied with the instrument to ensure the electrodes have the proper distance between them. The table height is easily adjustable to ensure the proper angle of the electrodes and height of drops. The rest of the test is controlled from outside the test chamber with the door closed.
The voltage, limiting current, drip rate and number of drips are all set on the control panel. An operator should observe the test to see if a flame ignites. The instrument sounds an alarm if there is a tracking failure of at least two seconds.
3. Our products include: Glow wire tester, Needle flame tester, horizontal and vertical burning tester, Tracking Index Tester, textile burning tester, protective clothing thermal conductivity tester, automotive interior combustion tester, melt dripping tester, building materials flammability tester, friction tester, test finger, spring hammer, universal testing machine and other testing instruments.
4. AUTOSTRONG is the eligible testing and measuring equipment supplier which has been recommended by IECC. It's one of leading enterprises in Hong Kong specialized in the R&D and manufacture of testing instruments, with more than 60 researchers from foreign countries, Hong Kong and Mainland China.
AUTOSTRONG supplies standard or customized solutions and products for many tests, measurements and quality control tasks required in the field of cable, wire, socket, plug, switch, plastic and rubber testing. All of our products are complying with the requirements of many standards, such as IEC, UL, VDE, VS, JIS, GB and so on.
Please feel free to contact us if you are interested in our products. We'll be very happy to give your the best quotation on your detail requirements.
